This is not a kit for absolute beginners.
Must be 18 years of age or older to purchase.
This Bot is NOT a toy. Do not test or operate this bot outside a suitable
enclosed arena that has a minimum of 1/4" thick polycarbonate walls.
Failure to follow this instruction may result in severe injury.

Video Instructions: Click Here
(Please pay attention to notes in Lobotomy build video description for changes)
Wiring Instructions PDF: Click Here
Prepare for Battle instructions: Click Here
CAD or STL Files NOT Available

Fights & Competition Awards
1st place Oregon State - Post Covid Battle 2021
1st place  Sactown Smack Down 2018
2nd place Hornet Combat @ CSUS  2019
2nd place Oregon State Bot Brawl 2019
2nd place Santa Slam 2020 (Under the name "Hunter")
3rd Place NorCal Robotics Expo 2019
Featured Article Make Magazine
Fight Videos (Click Here)

Battle Robot Kit 'Taserface' comes with everything you need to get started in combat robotics (Except Transmitter, Receiver & Battery charger sold separately).
- FingerTech's New Blade Mount
- UHMW chassis (Ultra High Molecular Weight Polyethylene) has plenty of strength and is repairable with Quicksteel Epoxy Putty.
- *Two 250 RPM gear motors for drive motors*
- 2.25-inch Snap Wheels and Snap Hubs provide both speed and pushing power.
- *Brushed Speed Controller Dual Way Bidirectional ESC 5A support 2S-3S Lipo*
- *FingerTech 3.5inch x 3mm  Titanium Weapon Disk*
- Polycarbonate combat armor lid keeps the components safe.
- *D2822/17 Brushless Outrunner 1100KV with 3.175mm shaft*
- *2S Rechargeable 400mAh lipo battery pack*
- All screws and hardware included to mount the motors and top armor.
- *Toggle power switch*
- *3mm thick Carbon Fiber Motor Mount*

*See competition upgrade*

Competition Upgrade includes:
- Competition grade Fingertech Silver Spark motors 50:1 & support bearings to insert into chassis.
- Competiton grade ESC "Scorpion Nano tiny dual-channel speed control". Save weight and provide a more controlled drive.
- 3S Battery Galaxy 3S High Discharge Rate for more power.
- BEC. Which is suggested with 3S battery to prevent the occasional brownout.
- Competition-grade FingerTech Mini Power Switch
-  4mm shaft motor for a stronger weapon mount (Drilling the carbon fiber arm 8mm hole to 9mm is required with 4mm shaft motor).
- UHMW Weapon Motor Guard
- 4mm thick Carbon Fiber Motor Mount

Dimensions:
Body Width: (6in)
Length: (5.5in)
Body Height: 1in
Weight: 420grams (14.82oz)

Requires:
- Transmitter and receiver
- LiPo Charger 2S-3S Balance Battery Charger 7.4-11.1V

- Tools Required:
Standard hex wrenches
Crosshead screwdriver
7/16” open-end or adjustable wrench
Wire stripper
Soldering iron and solder (60/40 rosin core type recommended).
Grinding device or hack saw to shorten screws if needed

Prepare for Battle!  (How to Videos)
Battle-harden motors with epoxy
Thread lock all bolts and set screws
QuickSteel epoxy putty to patch your chassis
Solder all wire connections
Hot glue gun to strengthen wire connections

Pre Assembled: If ordering without ordering a remote & receiver at the same time from us then drive motors might need to be reconfigured due different wiring scenarios and programming of the remote you chose to use. We will hook up and test with a Flysky T6A 2.4GHz 6-Channel Radio Transmitter & Receiver. All connections will be soldered for stronger connection instead of using power blocks. Pre-assembled does not include loctite on connections so you might want to go through and loctite any hardware that might vibrate loose during battles
